Low pressure (Vac Vac)

This type of autoclave is used to achieve treatment according to class 2. Wood treated in this way protects against insects and fungi and should only be used in indoor settings.

In this process, the wood is vacuumed and then impregnated at low pressure.

Depending on the customer's needs, a standard solution with selected options can be chosen, up to a fully automatic installation with supply and discharge conveyors with or without storage.

This type of autoclave is made square or cylindrical.
   •    Square tank (1,5m x 1,5m)
        o    Available pack size
              ►   H=1,2m ; W=1,2m
        o    Pack length according to the length of the autoclave
              ►   To be chosen according to the customer's needs

   •    Cylindrical tank
        o    Pack size according to the diameter
              ►   Dia 1.6m : H=1.0m ; W=1.0m
              ►   Dia 1.8m : H=1.2m ; W=1.2m
              ►   Dia 2.0m : H=1.3m ; W=1.2m
              ►   Dia 2.5m : H=1.8m ; W=1.2m
              ►   Dia 3.0m : H=2.4m ; W=1.2m
        o    Pack length according to the length of the autoclave
              ►   To be chosen according to the customer's needs

The autoclaves are always designed according to the wishes and needs of the customer. With our various options the most efficient configuration can be selected:
   •    Automation: door, bridge, loading to fully automatic warehouse.
   •    Tilt system
   •    Clamp system
   •    Baffels
   •    Dosing systems
   •    Various storage tanks
   •    Two doors
   •    …
